产品概述 Product description
进口单级单吸立式离心泵是本公司参照国际ISO2858和国家标准JB/T6878.2-93所规定的性能参数，结合本公司多年生产经验而设计的第二代高效节能产品，是替代管道离心泵、多级离心泵等常规泵的理想产品

Import single stage single suction vertical centrifugal pump is designed with reference to the Company's performance parameters under international ISO2858 and national standard JB / T6878.2-93, combined with the company many years of experience in the production of the second generation of energy efficient products is an alternative pipeline ideal for centrifugal pumps, multistage centrifugal pumps and other conventional

产品特点 Features
泵为立式结构，进出口口径相同，且位于同一中心线上，可象阀门一样安装在管路之中，外形紧凑美观，占地面积小，建筑投入低，如加上防护罩则可置于户外使用。叶轮直接安装在电机的加长轴上，轴向尺寸短、泵与电机轴承配置合理，能有效地平衡泵运转产生的径向和轴向负荷，从而保证了泵的运行平稳，振动噪音很低。安装检修方便面，无需拆动管路系统，只要卸下泵联体座螺母即可抽出全部转子部件。可根据使用要求即流量和扬程的需要采用泵的串、并联运行方式。可根据管路布置的要求采用泵的竖式和横式安装。 系列流量范围1.5～1600m3/h，扬程范围5～125m，分基本型、分流型、切割型等多种规格
Pump for the vertical structure, import and export of the same caliber, and in the same center line as the valve installed in the piping into the compact appearance, small footprint, construction investment is low, such as with protective cover can be set for outdoor use. Impeller mounted directly on the shaft extension, short axial dimension of the motor, pump and motor bearing arrangement is reasonable, can effectively balance the radial and axial loads generated by operation of the pump, thus ensuring the smooth operation of the pump, low vibration and noise. Installation and maintenance of instant noodles, no need to open the pipeline system, as long as remove the pump conjoined nut to be pulled out all the rotor housing member. That may require the use of pump flow and head of series and parallel operation mode according to requirements. The pump may be employed in accordance with requirements of piping layout vertical and horizontal installation. Series Flow range 1.5 ~ 1600m3 / h, head range 5 ~ 125m, basic type, shunt type, cut type, and other specifications

产品用途 Product Usage
立式管道离心泵，供输送清水及物理化学性质类似于清水的其它液体之用，适用于工业和城市给排水、高层建筑增压送水、园林喷灌、消防增压、远距离输送、暖通制冷循环、冷暖水循环增压及设备配套，使用温度＜80℃。

Vertical pipeline centrifugal pump for conveying water and physical and chemical properties similar to water or other liquids for industrial and urban water supply and drainage, high-rise building pressurized water, garden irrigation, fire booster, long-distance transmission, HVAC refrigeration cycle, warm and cold pressurized water cycle and supporting equipment, the use of temperature <80 ℃.
